Bars/ Wire-rod Shot Blast Machine

Bars/ Wire-rod Shot Blast Machine

  • Min.Order Quantity: 1 Set
  • Supply Ability: 100 per Year
  • Port: QingdaoChina
  • Payment Terms: L/C,T/T
Get Latest Price:
  • *Quantity: Set/Sets
| Factory
Experience:2002-03-20
Buyer Protection

- Guaranteed Secure Payments on Every Order

- Refund if your item is not delivered or as described

- Buyer Protection after order confirmation

Latest Browsing
Product Details
  • Size:  25
  • Place of Origin:  China
  • Brand Name:  Wantong Foundry Equipment
  • Model Number:  WQPY Series
  • Weight: 10000.000 kg

Rewarded by CFA(Chinese Foundry Association), a new type of wire-rod batch processing shot blast system was brought to the public after 6 years’ research & design. Wantong listened to our customer and understood their demand, the innovative wire-rod shot blast system serves for many industries like, reinforced bar making, machining work, bolt, screw, nail making, etc...


Instead of single piece processing machines, WQPY can process a batch of wire-rod once with Max. Weight up to 2.5 tons, and finish the surface cleaning job within 7-8 minutes.Moreover, the rotation type loading worktable allows to load the work-pieces when another batch being processing at same time. Advantages of the WQPY machine include: high efficiency, less media consumption, improved machine uptime, less space share, and low noise.


Initiation in China. Instead of traditional acid washing methods, double cantilever axial type WQPY wire-rod shot blast machine applies rotation type Gate with duel worktable plus duel cantilever eccentric shaft to load the wire-rod for processing. Full cast alloy steel cantilever shake the wire-rod up and down, left and right, and clockwise and anti-clockwise direction to make sure every surface of the job is cleaned thoroughly. All motions are controlled by PLC, and the machine allows HMI monitoring with friend panel for easy operation.

The Main machine body is available in full cast Mn30% steel high wear resistance liner which has a long life circle 5-10 times longer than conventional material. The abrasive safety door will auto close when the main gate rotates to protect the operators.


Two cantilevers installed separately beside the door allows loading/unloading job to be done when the indoor shot blasting job is operating. Max. Loading ability is up to 2500 kg/cantilever, and the machine is mounted with 6 - 10 sets of wheel blaster (according to the customer’s needs, motor power can be designed with many options).

Optional alternation/choice

l Controllable transducer for each wheel motor

l Motor power can be designed according to job requirement

l Larger capacity chamber can be designed & manufactured as per requirement


  • Size:  25
  • Place of Origin:  China
  • Brand Name:  Wantong Foundry Equipment
  • Model Number:  WQPY Series
  • Weight: 10000.000 kg
